Name: AXR EL Ribbon – Resin Thermal Transfer Ribbon for Electronics Industry
Brand: Armor
Availability: PreOrder

Technical Specifications

Specifications	Details
Product Name	AXR EL
Ribbon Type	Premium Resin (Expert)
Compatible Printer Type	Flat Head
Maximum Print Speed	8 IPS (200 mm/s)
Ink Melting Point	75°C / 167°F
Heat Resistance	Up to 300°C (572°F)
Abrasion Resistance	Very High
Chemical & Solvent Resistance	Resistant to alcohol, acetone, gasoline, oil, etc.
Compatible Materials	Synthetic materials (specialized labels for electronics industry)
Ribbon Structure	3 layers: Resin ink – 4.5μm PET film – back coating (anti-friction)
Back Coating Friction Coefficient	Kd < 0.2
Certifications	UL 969, FDA, EU 1935/2004/EC, RoHS, REACH, Prop 65
Storage Conditions	5–35°C, 20–80% RH, avoid direct sunlight
Recommended Shelf Life	Within 12 months from date of manufacture

Detailed Description

AXR EL Ribbon is a premium resin thermal transfer ribbon engineered specifically for electronics labeling applications, including PCB boards, electronic components, batteries, and power devices.

This high-performance ribbon delivers excellent adhesion, superior heat resistance, and outstanding chemical durability, making it ideal for applications that require long-term stability and full traceability throughout the product lifecycle.

Key Advantages of AXR EL Ribbon

Extreme heat resistance up to 300°C (572°F) – ideal for PCB soldering processes
Excellent resistance to chemicals, solvents, alcohol, and harsh cleaning agents
High-definition barcode printing – perfect for small text, 1D/2D barcodes, and QR codes
Optimized for specialized synthetic labels used in the electronics industry
Certified to UL 969, RoHS, REACH, Halogen-Free standards
